Standard Plans Review Package: Origination Form, Red Lines, and DRAFT Implementation.
  Standard Plans Comments: Click on the corresponding Comments link to submit a question or comment.

   REVIEW ENDING DATE: 07/30/2025
 Standard
 Plans
 Review
 Package		 Index Title Standard
 Plans
 Comments
102-120Low Profile BarrierComments
102-200Temporary Acrow 300 Series Detour Bridge
102-210Temporary Detour Bridge - Timber Pile Foundations
102-220Temporary Detour Bridge - Steel H Pile Foundations
102-230 Temporary Detour Bridge - Steel Pile Pipe Foundations
400-090Approach Slabs (30 ft.) (Flexible Pavement Approaches)
400-091Approach Slabs (30 ft.) (Rigid Pavement Approaches)
455-03030 " Square Prestressed Concrete Pile
455-03130" Square Prestressed Concrete Pile - High Moment Capacity
455-06060" Prestressed Concrete Cylindrical Pile
521-404Guardrail Transitions - Existing Post and Beam Bridge Railings (Narrow and Recessed Curbs)
630-010 Conduit Details - Embedded
700-012Single Post Sign Support Barrier Side-Mounted
700-020Multi-Column Ground Sign
706-001Typical Placement of Raised Pavement Markers
711-001Pavement Markings
711-003Interchange Markings
